| INDIAN RAILWAY STANDARD RAILS (IRS-T-12-2009) | |||||
|---|---|---|---|---|---|
| Size | Dimension (mm) | Weight (Kg/m) |
|||
| Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
||
| 52 kg | 67 | 156 | 136 | 15.5 | 51.89 |
| UIC60 kg | 74.3 | 172 | 150 | 16.5 | 60.34 |
