| AMERICAN STANDARD RAILS (ASTM A1) | ||||||
|---|---|---|---|---|---|---|
| Size | Dimension (mm) | Weight (Kg/m) |
Weight (lbs/yd.) |
|||
| Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
|||
| ASCE 25 | 38.1 | 69.85 | 69.85 | 7.54 | 12.4 | 25 |
| ASCE 30 | 42.86 | 79.38 | 79.38 | 8.33 | 14.88 | 30 |
| ASCE 40 | 47.62 | 88.9 | 88.9 | 9.92 | 19.84 | 40 |
| ASCE 60 | 60.32 | 107.95 | 107.95 | 12.3 | 29.76 | 60 |
