| INDIAN STANDARD LIGHT RAILS (ISLR-3964-1980) | |||||
|---|---|---|---|---|---|
| Size | Dimension (mm) | Weight (Kg/m) |
|||
| Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
||
| ISLR 12 | 35.72 | 69.85 | 60 | 6.75 | 12 |
| ISLR 15 | 41.28 | 79.38 | 76.20 | 7.54 | 14.9 |
| ISLR 25 | 52.39 | 104.78 | 100.01 | 9.92 | 24.9 |
